Electric Golf Cart

Heritage D HD60

Electric carts for courses, resorts and communities. Match the seating configuration to your daily operation.

Explore customization services

Seats
6
Range
70 km 43 mi
Top speed
≤ 25 km/h ≤ 16 mph · adjustable
Motor
5 kW 48 V AC

Choose your configuration

Seating

Ask for a loading plan, production timing and service parts in the written quote.

Heritage D HD60, 6 seats

Ready for the everyday route.

Heritage D HD60 at a glance

The Heritage D HD60 is a 6 to 8 seater electric golf cart from the Heritage D series, built for golf course fleets, resorts and residential communities.

Its published 2025 sheet lists a 70 km (43 mile) base range, a top speed of up to 25 km/h (16 mph), a 48 V system with a 5 kW motor and an 8-hour charge time. Power comes from deep-cycle, maintenance-free lead-acid batteries.

Heritage styling on a 1,215 mm body for a wider seat and more hip room per bench, while keeping the traditional profile and the low purchase price.

Dealers and fleet buyers order it wholesale by container, with configuration, colour and branding confirmed in the written quotation.

  • Overall3780 x 1215 x 1870 mm148.8 x 47.8 x 73.6 in
  • SeriesHeritage DGolf Carts
  • Seating6–8configurable

2025 model year

Full specification

Reproduced in full from the manufacturer's configuration sheet, revision 20250901. Imperial values are converted, not separately measured. First-party specification; not independent validation.

6 seats

Heritage D HD60 — 6 seats specification
Overall L x W x H 3780 x 1215 x 1870 mm148.8 x 47.8 x 73.6 in
Wheelbase 3100 mm122 in
Seating capacity 6
Kerb weight ≤ 550 kg (with batteries)≤ 1213 lb (with batteries)
Gross vehicle weight 1060 kg2337 lb
Track, front / rear 850 / 970 mm33.5 / 38.2 in
Ground clearance 110 mm4.3 in
Turning radius, outer ≤ 4.8 m≤ 15.7 ft
Range 70 km43 mi
Top speed ≤ 25 km/h, adjustable≤ 16 mph, adjustable
Max gradient, laden ≤ 15%
System voltage 48 V
Motor 48 V 5 kW three-phase AC induction motor, copper-wound, high torque and low noise
Controller 48 V 350 A three-phase AC controller with stepless CMOS drive, regenerative electronic braking, anti-rollback, automatic downhill speed limiting and programmable mapping
Battery Six 8 V 150 Ah deep-cycle maintenance-free lead-acid batteries
Charger On-board intelligent high-frequency charger, 220 V AC input, 48 V DC / 25 A output
Charge time 8 hours
Chassis High-strength steel ladder-frame chassis, electrophoretic primer plus powder coat
Front axle and suspension Multi-leaf springs with hydraulic dampers
Rear axle and suspension Multi-leaf springs with hydraulic dampers
Brakes Mechanical drum brakes with self-releasing park function and automatic slack adjustment
Steering Single-stage rack-and-pinion steering with drag link
Tyres and wheels 205/50-10 highway tyres, 6-ply rated, P820 tread on steel rims
Body High-strength composite body with an injection-moulded PP front cowl for impact resistance
Canopy High-strength vacuum-formed ABS, white
Glazing Flat acrylic windscreen
Floor Textured rubber floor
Seating High-density foam cushions in PVC leatherette
Steering wheel Injection-moulded steering wheel with scorecard holder (R40)
Dash and instrumentation Key switch, direction selector, ball and tee holders, cup holders and a round TFT display showing voltage, state of charge, speed and odometer
Lighting and signalling Combination headlamps, indicators, combination tail lamps, horn and reversing buzzer
Front bumper Injection-moulded mudguard
Additional standard equipment
  • Side mirrors
Electric vehicle chassis on an assembly line

Plan beyond delivery

A vehicle is part of a bigger plan.

Start with the configuration. Then plan the order, the charging setup and the service parts that keep your fleet supported.

  1. 01

    Define your specification

    Confirm seating, body options and requirements for your market.

  2. 02

    Plan the order

    Share your quantity and destination for loading and pricing.

  3. 03

    Match the parts

    Build a service package around your model and revision.

Build my fleet quote ↗

Questions about the Heritage D HD60

How many seats does the model Heritage D HD60 have?

The Heritage D HD60 is published in 6 and 8 seat configurations; choose the layout in your quotation.

How fast does the model Heritage D HD60 go?

Up to 25 km/h (16 mph) on the published sheet, and the top speed can be limited in the controller for your site.

What is the range of the model Heritage D HD60?

The published base range is 70 km (43 miles) per charge, with an 8-hour charge time. Real range depends on load, gradients and driving style.

How much does the model Heritage D HD60 cost?

The Heritage D HD60 is sold wholesale by quotation. The price depends on the configuration, battery, options, quantity and destination; send your order details for a written quote.

Also consider

Nearby in the range

These models share this vehicle category and are ordered by seating proximity. Compare this model's 6 base seats and 70 km published base range with each alternative.

Get a quote

Pricing for the Heritage D HD60

Tell us the quantity, seating configuration and destination port. Request a loading plan and available freight costs in the written quote.

  • Request a loading plan for your model mix
  • Ask for available FOB pricing and freight costs
  • Confirm lead time after agreeing the specification
  • Discuss service parts for each selected configuration
